Foredom M.SR-2 230V Motor Only - Otto Frei
Foredom

Foredom M.SR-2 230V Motor Only

Part # 134.189-230V Only 1 left Weight -- lb / -- g
Limited time deal -15%
$253.54
List Price: $298.29
220V / 240V supply only. This unit requires higher-voltage supply (220V / 240V). Plugging it into a standard North American 110V / 120V outlet will prevent it from running properly and voids the warranty. Confirm your outlet voltage before powering on. Learn more

Foredom M.SR-2 230V export flex shaft motor for 220–240 V regions, supplied with a standard key tip shaft and sheath for use with quick disconnect handpieces. The reversible 1/6 HP motor runs overhead with a smooth, steady pull while you grind, sand, drill, and polish.

Features

  • 1/6 HP ball bearing M.SR-2 230V motor for general jewelry, metalsmithing, and light industrial work
  • Reversible rotation helps control debris direction, refine symmetrical grinding, and back out stuck drill bits
  • Maintains power up to 18,000 RPM without stalling or slowing under normal load
  • Supplied with standard flexible shaft and sheath for connecting to Foredom and other quick disconnect handpieces
  • Export 230V version with North American 3-prong plug for use in 220–240 V regions (with appropriate plug adapter)
  • Two-year Foredom warranty for reliability in daily bench and workshop use

Specifications

Property Value
Motor Series M.SR-2 export model
Motor Type Ball bearing flex shaft motor
Motor Power 1/6 HP
Maximum Speed Up to 18,000 RPM
Rotation Direction Reversible (forward and reverse)
Voltage 230 V AC export version for regions with 220–240 V mains supply
Drive Type Key tip shaft for quick disconnect handpieces
Supplied Shaft & Sheath Standard flexible shaft and sheath included
Warranty Two-year Foredom motor warranty
Brand Foredom

What's Included

Item Description
M.SR-2 230V motor Reversible 1/6 HP, 18,000 RPM flex shaft motor, export 230V version with North American 3-prong plug
Flexible shaft Standard key tip inner shaft for connecting to quick disconnect handpieces
Sheath Standard outer sheath matched to the supplied inner shaft

Compatibility

  • For use in countries or regions where 230 V (220–240 V class) mains voltage is standard.
  • Must be used with a compatible Foredom speed control (not included); do not plug directly into a wall outlet.
  • Standard key tip shaft connects to Foredom and many other brands/manufacturers’ quick disconnect handpieces.

Notes

  • 230V export rating: M.SR-2 230V motor is intended for 230 V AC systems in regions with 220–240 V supply. It is supplied with a North American 3-prong 230 V plug—use a plug adapter that matches your local outlet. Do not use on 100–127 V circuits.
  • Never operate the motor without a proper Foredom speed control; plugging directly into mains power can damage the motor and is unsafe.
  • In reverse, screw-top mandrels with loose polishing wheels may unscrew—use pre-mounted wheels permanently fixed to mandrels when running in reverse.
  • Alternating forward and reverse directions can help extend abrasive life and improve symmetry when grinding, carving, or polishing.
California Prop 65 Warning California Prop 65 Warning:
This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, birth defects or other reproductive harm. www.P65warnings.ca.gov.
Brand
Foredom
Part #
134.189-230V
Type
Rotary Tools
Voltage
220V / 240V
Dimensions
19 in x 12.5 in x 4.5 in
