Glardon-Vallorbe Crossing Needle Files - LA2403

Part # LA2403-100-2

Single unit weight: -- lbs / -- kg

$22.85
Availability:
12 in stock, ready to be shipped
Availability:
7 in stock, ready to be shipped
Availability:
7 in stock, ready to be shipped
Availability:
Only 4 left!
Availability:
12 in stock, ready to be shipped
Availability:
11 in stock, ready to be shipped
Availability:
6 in stock, ready to be shipped
Availability:
62 in stock, ready to be shipped
Availability:
25 in stock, ready to be shipped
Availability:
10 in stock, ready to be shipped
Availability:
9 in stock, ready to be shipped
Availability:
13 in stock, ready to be shipped
by Glardon-Vallorbe
Select Length & Cut: 100-2

Product Details

Glardon-Vallorbe crossing needle files are Swiss-made precision tools built for professional jewelers and metalsmiths who demand accuracy and longevity. Featuring round handles, these files are measured tip to tip, including the handle. The cutting length is measured from where the teeth begin to the end of the file.

Crossing files are half round on two sides, with one side having a larger radius than the other. They taper in both width and thickness and are cut and usable all the way to the point. They are used primarily for filing interior curved surfaces, and the double radius makes it possible to file at the junction of two curved surfaces.

Glardon-Vallorbe needle files are graded from 00 (coarsest) to 6 (finest). The higher the number, the finer the cut. Manufactured to precise production standards using a combination of machine cutting and hand craftsmanship, these files are made from the finest heat-tempered chrome alloy steel — delivering superior performance on all metals.

Features

  • Swiss made to precise production standards
  • Half-round profile on two sides with asymmetric radii for filing curved junctions
  • Tapered in width and thickness; cut and usable to the point
  • Round handles; length measured tip to tip, including handle
  • Heat-tempered chrome alloy steel construction
  • Available in multiple lengths (4"–7-7/8") and cuts (Coarse through X-Fine)
  • Measurements given are at the thickest point

Specifications

Origin Swiss Made
File Type Crossing Needle File
Material Heat-tempered chrome alloy steel
Handle Style Round
Length Measurement Tip to tip, including handle
Cut Length Measurement From where teeth begin to end of file
Cut Grade Scale 00 (X-Coarse) to 6 (X-Fine)
Available Lengths & Dimensions 100mm (4") – 3.5mm × 1.4mm; 140mm (5-1/2") – 4.4mm × 1.8mm; 160mm (6-1/4") – 5.1mm × 2.0mm; 200mm (7-7/8") – 6.0mm × 2.4mm

Available Options

Part # Legacy Part #s Length Cut
LA2403-100-2 131.485 & 31.485 4" (100mm) Cut 2 – Medium
LA2403-100-4 131.486 & 31.486 4" (100mm) Cut 4 – Fine
LA2403-140-0 131.487 & 31.487 5-1/2" (140mm) Cut 0 – Coarse
LA2403-140-2 131.488 & 31.488 5-1/2" (140mm) Cut 2 – Medium
LA2403-140-4 131.489 & 31.489 5-1/2" (140mm) Cut 4 – Fine
LA2403-160-0 131.490 & 31.490 6-1/4" (160mm) Cut 0 – Coarse
LA2403-160-2 131.491 & 31.491 6-1/4" (160mm) Cut 2 – Medium
LA2403-160-4 131.492 & 31.492 6-1/4" (160mm) Cut 4 – Fine
LA2403-160-6 131.493 & 31.493 6-1/4" (160mm) Cut 6 – X-Fine
LA2403-200-0 131.494 & 31.494 7-7/8" (200mm) Cut 0 – Coarse
LA2403-200-2 131.495 & 31.495 7-7/8" (200mm) Cut 2 – Medium
LA2403-200-4 131.496 & 31.496 7-7/8" (200mm) Cut 4 – Fine
