Quatro DFH-1000B Ductless Burnout Fume Hood

The Quatro DFH-1000B Ductless Burnout Fume Hood delivers effective fume and odor control for wax burnout and plating operations — no exterior venting required. Designed for jewelers and metalsmiths working in enclosed studios or spaces where ductwork is impractical, this hood captures and filters harmful fumes through a robust 4-stage filtration system that removes 99.9% of odors and fumes before recirculating clean air back into the workspace.

At 26" high by 28" wide by 18" deep, the DFH-1000B provides a substantial working volume while maintaining a manageable footprint. It ships via truck freight only and runs on standard 115V/60Hz power.

Features

• 4-stage filtration system removes 99.9% of odors and fumes
• No exterior venting or ductwork required
• Ideal for wax burnout and plating fume control
• Standard 115V/60Hz operation
• Substantial hood interior for burnout applications
• Ships via truck freight

Specifications

Notes

The DFH-1000B uses the following replacement filters, available separately from Otto Frei:

• Stage 1: F007 Filter — Otto Frei #147.625
• Stage 2: F033-GPC Filter — Otto Frei #147.624A
• Stage 2 Charcoal Refill: NC-GPC — Otto Frei #147.628D
• Stage 3: F033-APC Filter — Otto Frei #147.624B
• Stage 3 Charcoal Refill: NC-APC — Otto Frei #147.624D
• Stage 4: F022 HEPA Filter — Otto Frei #147.626C

This item ships by truck freight only. Please plan accordingly when placing your order.
